AS1428.1:2021- Technical article 1-Application of 1500mm clear width to Curved walkways/ramps
AS1428.1:2021- Bite size technical article 1 - Application of 1500mm clear width to Curved walkways and ramps
AS1428.1:2021 (Desing for Access and Mobility) Clause 7.4(f) Curved walkways, ramps and landings
The AS1428.1-2009 Clause 10.4 the following for curved walkways and landings requires:
- Gradients (as per Figure 20)
- Landings (as per Clause 10.8)
- Length of curved ramp to be measured along its centreline
- All curved ramps/ walkways to have a clear minimum width of 1500mm
- Any crossfalls to be towards the centre of curvature
The clause caused confusion in the following areas:
- What is the definition of a 'curved' walkway or ramp? Would say a gentle 20M radius walkway still be considered to be a ‘curve’ and require 1500mm clear width?
- What would the junction of a 1000mm straight walkway with a 1500mm curved walkway look like?
To clarify this the AS1428.1:2021 has been updated to state the following:
- The curved ramps are now defined as being maximum inside radius of 5M. Therefore, any curved ramps that have an internal radius of more than 5M need not provide a clear width of 1500mm but can remain a minimum of 1000mm.
- At the junction of a straight walkway / ramp and a curved walkway / ramp, a 1500mm long straight landing is required which:
- Intersects with each other along the centreline
- The change in width from 1000mm (straight component) to 1500mm (curved component) is to be accommodated within the length of the 1500mm long straight landing.
